🌐 Network & Port Configuration
8 × Gigabit PoE RJ-45 ports for cameras and powered devices (IEEE 802.3af / 802.3at).
2 × Gigabit RJ-45 uplink ports for linking to routers, NVRs, or other switches.
Total PoE power budget: approximately 60 W (varies by version/model).
Each PoE port can deliver up to ~30 W per device.
⚡ Power over Ethernet (PoE) Features
Supports standard PoE/PoE+ (IEEE 802.3af/at).
PoE Watchdog automatically detects and reboots unresponsive cameras.
Long-Range PoE transmission up to 300 m for extended cable runs (depending on camera/cable).
6 kV surge protection to safeguard devices from electrical spikes.
🧠 Smart Management Functions
The switch supports advanced Layer-2 network features, including:
VLAN (802.1Q) for segmenting network traffic.
Loop prevention (STP/RSTP) to avoid network broadcast storms.
Port isolation to enhance security between devices.
Link aggregation (static) for higher bandwidth and redundancy.
Cable diagnostics to detect and locate cable faults.
Management protocols: Web user interface, Hik-Partner Pro, and Hik-Central Pro for remote monitoring and configuration.
🖥️ Performance & Hardware
Switching capacity: ~20 Gbps
Packet forwarding rate: ~14.88 Mpps
MAC address table: 4 K entries
Internal cache: ~1.5 Mbits
Compact, fanless metal chassis for quiet and reliable operation.
Can be desk-mounted or wall-mounted.
📊 Typical Uses
✅ CCTV and IP camera systems
✅ Small to mid-size network deployments
✅ Offices and retail environments requiring managed PoE networking
✅ Installations needing remote monitoring & power control
