CUDY AX3000 Ceiling Mount Wi-Fi 6 Access Point

CUDY AX3000 Ceiling Mount Wi-Fi 6 Access Point

Model VersionAP3000 1.0
CPUChipsetMT7981BA
 CPU Details1.3 GHz Dual-Core CPU
Memory/StorageFlash/ROM256 MB '2 Gbit' NAND
 DDR/RAM512 MB '4 Gbit' DDR4
Wireless5 GHz Wi-Fi Speed2402Mbps
 2.4 GHz Wi-Fi Speed574 Mbps
 5 GHz Wi-Fi Streams3T3R '3×3 MIMO'
 2.4 GHz Wi-Fi Streams2T2R '2×2 MIMO'
 Wi-Fi Antennas5× Internal
 5 GHz Antenna Gain Max5.6 dBi
 2.4 GHz Antenna Gain Max4.8 dBi
 FEM or PA/LNA
  • 5 GHz: 3× High-Power
  • 2.4 GHz: 2× High-Power
 BeamformingTrue
 Range PerformanceMax: 200 m '656 ft'
Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
 Wall PerformanceTwo wooden walls with thickness < 10 cm '4'''
One concrete wall with thickness < 20 cm '7''' or two concrete walls with thickness < 10 cm '4'''
Interfaces2.5G RJ45 Ports1
 Ethernet NotesAccepts PoE powering
 LEDSystem
 Physical ButtonsReset Button
 Power InputDC Jack, PoE via Ethernet Port
PowerPower Methods
  • DC
  • 802.3at/af PoE
  • Passive PoE
 DC12V 1.5A
 Passive PoE48 ~ 57V
 Power AdapterAP3000 | DC Adapter in the box:
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1.5A DC
AP3000_P | PoE Adapter in the box:
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 48V Passive PoE
 Max Power Consumption 'W'12 W '48 V PoE' 12 W 'DC'
 Idle Power Consumption 'W'6.1 W '48 V PoE' 6.1 W 'DC'
ReliabilityAdvancedHardware Watchdog
 ESD Contact Protection4kV
 ESD Air Protection8kV
 EnvironmentOperating Temperature: -10 ℃ ~ 60 ℃ '14 ℉ ~140 ℉'
Storage Temperature: -40 ℃ ~ 70 ℃ '-40 ℉ ~ 158 ℉'
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
CertificationsFCC, CE
MechanicalInstallation
  • Wall-mount
  • Ceiling-mount
 DimensionΦ231.9×57.1 mm
Φ9.13×2.25 inches
 Product Weight494 g '17.43 oz.'
Package Content
  • AP3000
  • Power Adapter
  • Mounting Kit
  • Ethernet Cable
  • Installation Guide
Ordering InformationRetail Package Weight
  • With PoE Adapter '_P' | EU: 1015 g '35.8 oz.'
  • With DC Adapter | EU: 941 g '33.19 oz.'
 Retail Package Dimension283×238×68 mm
11.14×9.37×2.68 inches
 Carton Net Weight
  • With PoE Adapter '_P' | EU: 20.3 kg '44.75 lbs'
  • With DC Adapter | EU: 18.8 kg '41.45 lbs'
  • With DC Adapter | UK: 19 kg '41.89 lbs'
 Carton Gross Weight
  • With PoE Adapter '_P' | EU: 21.7 kg '47.84 lbs'
  • With DC Adapter | EU: 20.0 kg '44.09 lbs'
  • With DC Adapter | UK: 20.2 kg '44.53 lbs'
 Units per Carton20
 Carton Dimension58×37.5×49.5 cm
22.83×14.76×19.49 inches
